SADDLE GUIDE AG420

• Galvanised carbon steel
• Available in stainless steel
• 600 DN and over comes with 4 bolt holes*
• Bolts not included
• Load recommendations are lateral only
• Custom versions and sizes available
• Manufactured in Australia
• Galvanised - up to 200°C

Add to Quote

Product Variants

Part Number
Pipe DN
ØD (mm)
C (mm)
ØH (mm)
J (mm)
SWL (Kg)
Item Weight (Kg)
Add to quote
AG420-02115288012242950.29
AG420-02720348612302950.32
AG420-03425429412372950.35
AG420-042325010515452950.39
AG420-048405611115512950.42
AG420-060506814715634200.77
AG420-076658616919794200.89
AG420-089809918219924201.29
AG420-114100124207191174201.40
AG420-141125150238241434201.53
AG420-168150178282241714201.76
AG420-194175204308241975603.36
AG420-219200229333242225603.74
AG420-245225255359242485604.10
AG420-273250283435242765604.47
AG420-324300334486243276807.91
AG420-356350366518243596809.10
AG420-406400416572284096809.82
AG420-4574504676232846068010.93
AG420-5085005186742851168012.17
AG420-5595505697252856268013.31
AG420-61060062077224*61468014.45
AG420-66065067082224*66468031.31
AG420-71170072187324*71596035.81
AG420-76275077292424*76696038.23
AG420-81380082397928*81996046.93
AG420-864850874103028*87096049.56
AG420-914900924108028*920 96052.13
AG420-101610001026118228*102296057.38
